FILTERING VERSION
In case fumes and vapour cannot be
discharged to the outside, the applian-
ce can be used in the ltering mode,
Activated charcoal lters are required in
this operation mode (g. 10). The air re-
cycled through the charcoal lters is then
re-circulated into the kitchen, thanks to
a duct conveying the air on one side of
the cabinet.
MOUNTING THE MOTOR
Only in the case of appliances equip-
ped with internal motor, it is possible to
mount the motor separately from the
hood; in this case, you will need to order
the dhk900 – 989580001 kit.
REMOVING THE GREASE FILTER,
FITTING THE ACTIVATED CHARCO-
AL FILTER
Grease lters and charcoal lters remo-
ving and tting operations shall be carri-
ed out with the downdraft open. To open
the downdraft, push the key .
.
Then remove the front panel by simulta-
neously pulling on the top of each side
(g. 8). The panel will rotate forwards,
thus allowing to reach the grease lters.
Remove the grease lters to reach the
charcoal lters . Charcoal lters shall be
replaced (g. 11) accordingly to actual
use of the Downdraft, in any case at le-
ast once every 6 months.
Caution: the lters protection panel shall
be re-t properly, otherwise the hood
might stop operation.
CONNECTING THE HOOD TO PO-
WER SUPPLY
 Thisapplianceisequip-
pedwithaH05VVFwith3x
0,75mm2conductors(neu-
tral,phaseandground)po-
wercord.
It shall be connected to a
220V–240Velectrical mo-
no-phasenetworkthrougha
CEI 60083 approved power
socket, which shall be ac-
cessibleafterinstallation,in
38
compliance with installa-
tionregulations.Wehereby
declineanyliabilityincase
of accidents due to failure
toconnectthe hood tothe
groundorincorrectground
connection.Thefuse to be
usedshallbe10or16A.In
caseofdamagestothepo-
wercord,pleasecalltheaf-
ter-sale service in order to
avoidanykindofrisk.
ELECTRICAL CONNECTION
This appliance complies with Europe-
an Directives 2006/95/CE (Low Voltage
Directive) and 2004/108/CE (Electroma-
gnetic Compatibility ) .
The hood shall be disconnected from po-
wer supply during installation and main-
tenance operations, while fuses shall be
disconnected or removed. Electric con-
nection shall be completed before tting
the appliance into the cabinet.
Check that:
- Power is adequate
- Power lines are in good conditions.
- Cables diameter is compliant with in-
stallation regulations.
 Caution
In case the hood shows any
anomalies, please disconnect
it or remove the fuse corre-
sponding to the appliance po-
wer disconnecting line.
