DeDietrich DME1140B Installation Manual

(2.10.2).
- Press the knob to confirm (2.10.3).
• “DEMO” MODE:
- Adjust the time to 00:00:00 (see section
“Resetting the time”)
Press the T°C, and STOP buttons
simultaneously for 10 seconds until DEMO
appears in the display. (2.11.1)
- To return to normal mode, set the time at
00:00.
- Press the T°C , and STOP buttons again
until DEMO goes off.
Caution
When the oven is in “DEMO” mode the
heating elements are inactive.
•STOPPING AND STARTING THE
TURNTABLE :
If you think that there is insufficient space
for the turntable to rotate freely in the oven, you
can stop it before or during the programme.
Stopping the turntable
- To stop the turntable rotating, press and hold
the knob (2.12.1). The (stop) symbol
appears in the display (2.12.2).
•
Restarting the turntable
- Once again, press and hold the knob until the
symbol disappears from the display
(2.12.2).
• THE “KEEP WARM” FUNCTION :
This function keeps the food at the
temperature it was when cooking finished.
Programming the “keep warm” function
- Select the KEEP WARM function (2.13.1), the
corresponding symbol flashes (2.13.2).
- Press the knob to confirm(2.13.3). The
cooking time flashes (2.13.4):
- Using the knob, set the required time the food
is to be kept warm (2.13.5)
for example, 4 minutes (2.13.6)
Press the knob to confirm, the lamp lights up
and the oven starts.
• AUTOMATIC COOKING FUNCTIONS :
Automatic cooking programme by weight.
— The programmer should only display the
time. It should not be flashing.
- Select mode (2.15.1)using the knob.
The logo flashes (2.15.2).
- Select the ICS cooking mode (2.15.3)
- Example: P2 —> weight, 500G (2.15.4).
- Adjust the weight, using the knob (2.15.5).
Example: 625g (2.15.6)
- Confirm by pressing the knob once (2.15.7).
- The icon of the cooking mode used and the
time calculated automatically are displayed.
The oven starts (2.15.8)
Note:
There are two possible automatic programmes
for cooking vegetables: P5 and P6.
(see chapter “GUIDE TO AUTOMATIC
COOKING”).
For quiches and fresh tarts, automatic cooking
programmes are not calculated by weight, but
based on a dish diameter between 27 and 30
cm.
a
2.15
2.13
2.12
a
a
2.11
a
english
