Specifications
Page 7 of 50
057-179 ISSUE: 3
3 SPECIFICATIONS
3.1 POWER SUPPLY
Minimum supply voltage
8 V continuous, 4 V for up to 5 minutes.
Cranking dropouts
Able to survive 0 V for 100 mS providing the supply was at least 8 V
before the dropout and recovers to 8 V afterwards.
Maximum supply voltage
32 V continuous (transient protection to 64 V)
Power up current
3 A transient inrush at initial power up.
Typical Operating current
630 mA at 12 V DC, 315 mA at 24 V DC
3.2 CONFIGURABLE I/O
Number
4 configurable general purpose input / outputs
Not currently fitted to the DSE892 – RESERVED for future use.
Rating
TBA
3.3 TERMINAL SPECIFICATION
Connection type
Screw terminal, rising clamp, no internal spring
Min cable size
0.5 mm² (AWG 20)
Max cable size
2.5 mm² (AWG 14)
3.4 USB HOST CONNECTOR
This USB type A socket provides support for connection to one DSE controller.
Use USB type A to USB type B cable.
NOTE: DSE stock a USB suitable cable for this purpose. Part number 016-125.
