Deerc D10 - Installation Guide; Propeller Installation; Drone Battery Installation

-10-
9.0 INSTALLATION
9.2 Drone Battery
9.1 Propellers
A B
B A
HEAD
The drone will not fly unless the correct propeller is installed on the correct
motor shaft. See illustration above. An “A” or “B” is printed on the each
propeller. Lock the propeller to the motor shaft with screw rotating each
screw clockwise.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
2
1
Installation: Push the battery into the battery compartment at the rear of
the drone. Make sure the battery is in place to ensure that the battery is
jammed in the battery compartment. (Pic.1)
Removal: Press and hold the lock on the battery at the same time while
pulling backwards to remove the battery. (Pic.2)
Pic.2Pic.1
