Deerc D20 - Installation Guide; Propeller Installation; Propeller Guard Installation

-11-
As shown in the picture, install the propeller guard to the motor base. Make
sure that the propeller guard are clamped to the motor base to avoid the
unnecessary loss and damage during flight.
9.0 INSTALLATION
9.2 Propeller Guard
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
9.1 Propeller
① Install the propeller on the motor shaft according to the “A/B”
corresponding position. (Pic1)
② Use a screwdriver to twist and tighten the screw by pressing the
clockwise direction. (Pic2)
A
B
B
A
Pic 1 Pic 2
HEAD
