-10-
8.1 Propeller
Installation: See illustration above, connect each propeller to its
corresponding motor shaft, either position “A/B”. Install the propeller to
the motor shaft and press into place.
Removal: First turn the bottom of the drone up and unscrew the
bottom screws. Then insert the propeller spanner between the
propeller and the motor. Be sure to hold the motor while detaching the
propeller.
8.0 INSTALLATION
A
B
HEAD
AB
A
B
Attention: Pay attention to the “A” or “B” printed on each
propeller. The drone will not fly unless the correct propeller is
installed on the correct motor shaft.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
