InstallationProduct
Handle assembly
Roller brush
Display
Power key
Sewage tank
removal key
Sewage tank
Press to turn on/o when the
main unit is not on the base.
Press to stop self-cleaning/ding
when the main unit is self cleaning
on the base.
Mode key
Press to change the
modes during cleaning.
Self-cleaning key
Sho press to turn on/o
self-cleaning/ding when
main unit is on the base;
Double-click to open
seperate ding mode.
Voice key
Press to turn on/o
voice prompt
Handle removal hole
Horn mouth
Clean water tank window
Clean water tank
Main unit inlet
Main unit charging po
LED display
Intelligent Charging Base Station
Power cord holder
Power po
Base tank handle
Cleaning Brush
Button
Cutter
Brush
Main Unit
Note: The illustrations of products, accessories and user inteaces in the manual are schematic diagrams for reference only. Due
to the updating and upgrading of the product, there may be slight dierences between the actual product and the schematic
diagram. Please refer to the actual product.
Installation of handle
Veically inse the connecting pipe of the
handle assembly into the corresponding
inteace of the device body in the direction of
arrow as shown in the gure, until there is a
"click". It is recommended to conrm again that
the handle is installed stably without looseness.
Installation of base
1. Inse the power plug into the power
connector on the back of the base, wind the
excess power cord on the power cord
holder, and leave a proper length of power
cord to clip it into the power cord slot.
3. Install the cleaning brush holder on either
side of the base stand, and place the
cleaning brush in the cleaning brush holder.
2. Place the base against the wall, and then
connect the power cord to the reliably
grounded wall socket.
•Do not place it near heat source or damp area (such as radiator, kitchen and bathroom).
•Do not disassemble, repair or ret the base without permission.
•Do not use any third-pay batte or rechargeable base. Only use it with the base model DEM-VX910W-JZ.
Caution:
Power cord holder
Power po
Power cord slot
Base tank cover
Cleaning brush holder
Tray
(detachable)
Base tank window
Base charging po
Base outlet
Tray outlet
Base tank
Base stand
最高水位
Side pressing plate of
oor brush
Side pressing plate
of oor brush
removal key
Upper removal cover
Upper removal cover
removal key
