DeFelsko PosiTector Series - Performance Requirements

Management Procedure 2585 Rev. F
5
5 Performance Requirements
Note: The technician will collect the data needed to complete column B of Table 5-1. Do
not write in this procedure.
Table 5-1 Performance Requirements and Calibration Data for PosiTector UTG
Reference
Thickness
(mm)
Min. Reading
Allowedn
(mm)
Max. Reading
AllowedY
(mm)
Actual Gage
Measurement
(mm)
A B
For imperial/metric readings convert using 1” = 25.4 mm
n For UTG-P: Calculation: A - 0.010 mm
For all other probes: Calculation: A - 0.03 mm
Y For UTG-P: Calculation: A + 0.010 mm
For all other probes: Calculation: A + 0.03 mm
