Pre-Installation
PLANNING INSTALLATION
Before installing the doorbell base, ensure that all parts are present. Compare parts with the Hardware Included and
Package Contents sections. If any part is missing or damaged, do not attempt to assemble, install, or operate this
doorbell base.
Estimated installation time: 30 minutes
NOTICE: If this doorbell is being connected to a video
doorbell, please call our dedicated technical service
group for assistance – 1-866-308-3976.
SPECIFICATIONS
Wired Installations Wireless Installations
Power requirements 16 volt AC, 10 watt or 16 volt AC, 15
watt transformer (no batteries are
allowed)
3 “C” alkaline batteries (when used as
a wireless doorbell base only)
TOOLS REQUIRED
Phillips
screwdriver
Flathead screwdriver Drill
Pliers Masking tape Pen
7/32 in.
(5.5 mm) Drill
bit
Wire strippers/cutters
Safety goggles Flashlight
