3.2 Display functions
3.2.1 Functional examples
The display indicates both readings and alarms.
The examples below are with icons and English language.
View examples
Appl. Ver.: 9.90.0
Service menu
Appl. Rev.: 0
Boot Ver.: 9.99.1
Boot Rev.: 0
The software version can be found in the Service menu
G P 0 kW
AMF MAN
G Q 0 kVAr
G S 0 kVA
Run absolute 0 hrs
Status, Generator P, Q and S. Run hours.
Serv1 1 d 0 h
AMF MAN
Serv2 1 d 0 h
Run absolute 0 hrs
Service timer 1 and 2.
Run hours.
Alarm acknowledge
G U-L1L2
ISLAND MODE
G U-L2L3
G U-L3L1
G f-L1
Press the OK button to enter the list of active alarms.
Alarm list:
Ch 1270 UNACK
1/1 alarm(s)
BB U> 1
The alarm list shows the active alarms. Press the OK button to ackowl-
edge alarms
Parameter settings
G U-L1L2
ISLAND MODE
G U-L2L3
G U-L3L1
G f-L1
Press the OK button to enter the parameter setting.
1000 Protections
SETUP MENU
2000 Synchronization
3000 Digital input
2500 Regulation
Select menu group with the OK button to edit.
CGC 400 Operator's manual 4189340787
UK
Display and menu structure
DEIF A/S Page 9 of 14
