OPERATION
• Valve opens by pressing on the push-button or pushing the lever.
AB Model: valve opens by pressing then releasing the push-button.
• Mixer: temperature selection by the side lever.
• Automatic shut-off after ~7 seconds for washbasins, ~3 seconds
or 7 seconds for urinals (depending on the model), and ~30 seconds
for showers (+5/-10 at 3 bar according to the European Standard
EN-NF 816).
(Other shut-off delays: TEMPOSTOP swan neck ~3 seconds, TEMPOSTOP
chain-pull shower and TEMPOSTOP shower 1/2” ~15 seconds).
INSTALLATION
• Tap: supply with cold water (insert the blue or grey marker)
or mixed water (insert the red marker).
• Mixer: supply with cold water and hot water at 50°C (maximum
recommended 70°C), and balance hot and cold water pressure
(∆P < 1 bar). Maximum pressure: 10 bar. Recommended dynamic
pressure: 1 - 5 bar. Take care not to pinch the flexibles (Fig. A).
• Respect the direction of the water flow, see arrow marked
on the valve body.
Deck-mounted washbasin model
• Drill hole diameter: Ø 21mm for taps or Ø 34mm for mixers.
• Mount the mixer/tap body onto the washbasin and tighten the nuts:
- Model with back-nut: tighten the 3 stainless steel screws
on the back-nut (Fig. B).
- Mixer: tighten the nuts (Fig. C) onto the fixing flange. Install
the filters (Fig. D) supplied as shown in the diagram.
They will protect the non-return valves.
• Ensure a suitable waterproof seal between the mixer/tap
and the work plan appropriate to the type of installation.
• Connect the water supply and activate the valve several times
to stabilise the timing.
Wall-mounted models
• Drill a hole Ø 21mm.
