Delfield 403 - Page 16

Compact Refrigerators and Freezers Service and Installation Manual
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.del eld.com
16
Hinge cartridge assy.
3234225
Cartridge brkt. BR, TL
3234226
Cartridge brkt. BL, TR
3234227
Pivot bracket BL, TR
3234228
Pivot bracket BR, TL
3234229
Shelf support
3234290
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Drier  lter
3516277
Condenser coil
3516296
Evaporator coil
3516298
Compressor R404A
3526939
Shelf 24”
3978160
Model D4448N-8
Description
Part #
Drawer kit
000ANF0033
Drawer gasket
1702541
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Temperature control
2194224
Caster 2”
3234148
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Drier  lter
3516277
Condenser coil
3516296
Evaporator coil
3516298
Compressor R404A
3526939
Model 4448N-12
Description
Part #
Door gasket
1702473
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Temperature control
2194224
Caster 2”
3234148
Hinge cartridge assy.
3234225
Cartridge brkt. BR, TL
3234226
Cartridge brkt. BL, TR
3234227
Pivot bracket BL, TR
3234228
Pivot bracket BR, TL
3234229
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Drier  lter
3516277
Condenser coil
3516296
Evaporator coil
3516298
Compressor R404A
3526939
Shelf 24”
3978160
Model D4448N-12
Description
Part #
Drawer kit
000ANF0033
Drawer gasket
1702541
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Temperature control
2194224
Caster 2”
3234148
Evaporator fan blade
3516274
Drier  lter
3516277
Condenser coil
3516296
Evaporator coil
3516298
Compressor R404A
3526939
Model 4448N-18M
Description
Part #
Door gasket
1702473
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Caster 2”
3234148
Hinge cartridge assy.
3234225
Pivot bracket BL, TR
3234228
Pivot bracket BR, TL
3234229
Support shelf
3234390
Thermometer hanging
3516135
Evaporator fan blade
3516274
Drier  lter
3516277
Condenser coil
3516296
Evaporator coil
3516298
Compressor R404A
3526939
Shelf 24”
3978160
Model D4448N-18M
Description
Part #
Drawer kit
000ANF0033
Drawer gasket
1702541
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Temperature control
2194224
Caster 2”
3234148
Hinge cartridge assembly
3234225
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Drier  lter
3516277
Condenser coil
3516296
Evaporator coil
3516298
Compressor R404A
3526939
Model 4460N-8, 4460N-12
Description
Part #
Door gasket
1702562
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Caster 2”
3234148
Hinge cartridge assy.
3234225
Cartridge brkt. BR, TL
3234226
Cartridge brkt. BL, TR
3234227
Pivot bracket BL, TR
3234228
Pivot bracket BR, TL
3234229
Shelf support
3234290
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Drier  lter
3516286
Condenser coil
3516297
Evaporator coil
3516298
Compressor 1/2HP R404A
3526945
Shelf 30”
3978162
Model D4460N-8, D4460N-12
Description
Part #
Drawer kit
000ANF0031
Drawer gasket
1702542
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Temperature control
2194224
Caster 2”
3234148
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Filter-dryer
3516286
Condenser coil
3516297
Evaporator coil
3516298
Compressor 1/2HP R404A
3526945
Model 4460N-12M, 4460N-18M,
4460N-24M
Description
Part #
Door gasket
1702562
Caster 2”
3234148
Hinge cartridge assy.
3234225
Cartridge brkt. BR, TL
3234226
Cartridge brkt. BL, TR
3234227
Pivot bracket BL, TR
3234228
Pivot bracket BR, TL
3234229
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Drier  lter
3516286
Condenser coil
3516297
Evaporator coil
3516298
Compressor 1/2HP R404A
3526945
Shelf 30”
3978162
Model D4460N-12M, D4460N-18M,
D4460N-24M
Description
Part #
Drawer gasket
1702542
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Temperature control
2194224
Caster 2”
3234148
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Filter-dryer
3516286
Condenser coil
3516297
Evaporator coil
3516298
Compressor 1/2HP R404A
3526945
Model D4464N, UCD4464N, STD4464N
Description
Part #
Drawer kit
000ANF0030
Drawer gasket
1702522
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Temperature control
2194224
Caster 2”
3234148
Thermometer hanging
3516135
Evaporator fan blade
3516274
Drier  lter
3516286
Condenser coil
3516297
Evaporator coil
3516298
Compressor 1/2HP R404A
3526945
Model 4464N-8, 4464N-12, 4464N-16
Description
Part #
Door gasket
1702475
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Temperature control
2194224
Caster 2”
3234148
Hinge cartridge assy.
3234225
Cartridge brkt. BR, TL
3234226
Cartridge brkt. BL, TR
3234227
Pivot bracket BL, TR
3234228
Pivot bracket BR, TL
3234229
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Drier  lter
3516286
Condenser coil
3516297
Evaporator coil
3516298
Compressor 1/2HP R404A
3526945
Shelf 32”
3978163
Model D4464N-8, D4464N-12 D4464N-16
Description
Part #
Drawer kit
000ANF0030
Drawer gasket
1702522
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Temperature control
2194224
Caster 2”
3234148
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Drier  lter
3516286
Condenser coil
3516297
Evaporator coil
3516298
Compressor 1/2HP R404A
3526945
Model 4472N-12, 4472N-18
Description
Part #
Door gasket
1702473
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Control temp
2194224
Caster 2”
3234148
Hinge cartridge assy.
3234225
Cartridge brkt. BR, TL
3234226
Cartridge brkt. BL, TR
3234227
Pivot bracket BL, TR
3234228
Pivot bracket BR, TL
3234229
Shelf support
3234290
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Drier  lter
3516286
Condenser coil
3516297
Evaporator coil
3516298
Compressor 1/2HP R404A
3526945
Shelf 24”
3978160
Model D4472N-12, D4472N-18
Description
Part #
Drawer kit
000ANF0033
Drawer gasket
1702541
Condenser fan motor
2162667
Condenser fan blade
2162681
Evaporator fan motor
2162691
Control temp
2194224
Caster 2”
3234148
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Drier  lter
3516286
Condenser coil
3516297
Evaporator coil
3516298
Compressor 1/2HP R404A
3526945
Model 4460N, ST4460N, UC4460N
Description
Part #
Door gasket
1702562
Control temp
2194224
Caster 2”
3234148
Hinge cartridge assy.
3234225
Cartridge brkt. BR, TL
3234226
Cartridge brkt. BL, TR
3234227
Pivot bracket BL, TR
3234228
Pivot bracket BR, TL
3234229
Accumulator
3516051
Evaporator fan blade
3516274
Drier  lter
3516286
Condenser coil
3516298
Evaporator coil
3516291
Shelf 30”
3978162
Model D4460N, STD4460N, UCD4460N
Description
Part #
Drawer kit
000ANF0031
Drawer gasket
1702542
Evaporator fan motor
2162691
Temperature control
2194224
Caster 2”
3234148
Accumulator
3516051
Thermometer hanging
3516135
Evaporator fan blade
3516274
Evaporator coil
3516298
Compressor 1/2HP R404A
3526945
Replacement Parts List
