Delfield 403 - Table of Contents; Receiving and Inspecting the Equipment; Serial Number Location

Compact Refrigerators and Freezers Service and Installation Manual
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.del eld.com
2
RECEIVING & INSPECTING EQUIPMENT
........................................
2
SPECIFICATIONS
...............................................................
..........
3-4
INSTALLATION
...............................................................
.................
5
CASTER INSTALLATION
...............................................................
..
6
CASTER/LEG MOUNTING DETAIL
...................................................
6
OPERATION
...............................................................
.....................
7
MAINTENANCE
...............................................................
................
7
DEFROSTING
...............................................................
...................
7
DOOR MAINTENANCE
...............................................................
.....
7
MAINTENANCE
...............................................................
.............
8-9
WIRING DIAGRAMS
...............................................................
......
10
DRAWER ASSEMBLY DRAWING
.............................................
11-12
DRAWER FRONT ASSEMBLY DRAWINGS
....................................
13
STANDARD LABOR GUIDELINES
..................................................
14
REPLACEMENT PARTS LISTS
.................................................
15-17
MANUFACTURERS LIMITED WARRANTY
....................................
18
STANDARD WARRANTIES
............................................................
19
NOTES
...............................................................
...........................
20
AUTHORIZED PARTS DEPOTS
..........................................
Back page
The serial number on all 400, 4000, 4400 and 4500 series
compact refrigerators and freezers is printed under the top
nosing directly above the door when door is in the closed
position. Above the right hand door on two and three door
models.
Always have the serial number of your unit available when
calling for parts or service. A complete list of authorized
Delfield parts depots is shown on the back cover of this
manual.
This manual covers standard units only. If you have a custom
unit, consult the customer service department at the number
listed below.
©2004 The Delfield Company. All rights reserved. Reproduction
without written permission is prohibited.
“Delfield” is a registered trademark of The Delfield Company.
Even though most equipment is shipped crated, care should
be taken during unloading so the equipment is not damaged
while being moved into the building.
1.
Visually inspect the exterior of the package and skid or
container. Any damage should be noted and reported
to the delivering carrier immediately.
2.
If damaged, open and inspect the contents with the
carrier.
3.
In the event that the exterior is not damaged, yet upon
opening, there is concealed damage to the equipment
notify the carrier. Notification should be made verbally
as well as in written form.
4.
Request an inspection by the shipping company of the
damaged equipment. This should be done within 10
days from receipt of the equipment.
5.
Check the lower portion of the unit to be sure legs or
casters are not bent.
6.
Be sure to check the compressor compartment housing
and visually inspect the refrigeration package. Be sure
lines are secure and base is still intact.
7.
Freight carriers can supply the necessary damage forms
upon request.
8.
Retain all crating material until an inspection has been
made or waived.
Receiving and Inspecting the Equipment
Contents
Serial Number Location
