F18 Series Service and Installation Manual
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com
18
F18MC
030-209-0030 Angle, Coil, Top Bae
3516053 Coil, solenoid, 120V/50/60HZ (rail)
*000-248-0030 Coil assembly, R404A
*000-248-0037 Coil assembly, R404A, Fan Lt
*000-BN5-0030 Condensing unit, 1/4hp, R404a
2194824 Control, Danfoss, GDM, 115V
2193927 Control, pressure, low
3234392 Hinge, pan cover, center
3234282 Hinge, pan cover, left
3234266 Hinge, pan cover, right
9321374 Hinge, pin (for pan cover)
0420068 Hinge kit, lo prole (left or right)
2190154 Switch, rocker
3516225 Valve, expansion (rail)
3516102 Valve, solenoid (rail)
3234645 Leg, 6", s/s
F18MR
030-209-0030 Angle, Coil, Top Bae
3516053 Coil, solenoid, 120V/50/60HZ (rail)
*000-248-0030 Coil assembly, R404A
*000-248-0037 Coil assembly, R404A, Fan Lt
2194824 Control, Danfoss, GDM, 115V
3234392 Hinge, pan cover, center
3234282 Hinge, pan cover, left
3234266 Hinge, pan cover, right
9321374 Hinge, pin (for pan cover)
0420068 Hinge kit, lo prole (left or right)
3234645 Leg, 6", s/s
9321041 Nut, acorn (for pan cover)
2190154 Switch, rocker
2194201 Thermostat, rail
3516225 Valve, expansion (rail)
3516102 Valve, solenoid (rail)
F18PD48
*000-248-0037 Coil assembly, R404A, Fan Lt
*000-BN5-0040 Condensing Assembly, 1/3-1/5 Stacked
2194824 Control, Danfoss, GDM, 115V
2194938 Control, Tstat, Danfoss, Etc1h-1
*000-402-0056 Cover Assembly, hinged, 6 pan, l/t
*000-187-006B Door Assembly, ref, 27x26, lt
3234645 Leg, 6, s/s, removable Foot
*356-478-0038 Panel, louver, 14.0, sw Cut, lh
3978014 Shelf, wire, coated
3234290 Support, shelf, plastic
2190154 Switch, rocker, 20a/125v
3516135 Thermometer, hanging, 4
F18PD72
*000-248-0030 Coil assembly, R404A
*000-BN5-003Y Condensing Assembly, 1/2-1/5 Stacked
2194824 Control, Danfoss, GDM, 115V
2194938 Control, Tstat, Danfoss, Etc1h-1
*000-402-0056 Cover Assembly, hinged, 6pan, l/t
*000-187-006B Door Assembly, ref, 27x26, lt
*000-187-006A Door Assembly, ref, 27x26, rt
3234645 Leg, 6, s/s, removable Foot
*356-478-0039 Panel, louver, 18.0, sw Cut, lh
3978014 Shelf, wire, coated
3234290 Support, shelf, plastic
2190154 Switch, rocker, 20a/125v
3516135 Thermometer, hanging, 4
Replacement Parts, continued
*Replacement part assemblies on pages 19-22.
