F18 Series Service and Installation Manual
7
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com
Specifications
Remote Refrigerated Reduced Height Rail
Model # Of Doors
Shelf Max
Load (lbs)
Base Volume
FT
3
Shelf
Area FT
2
Volts/Hertz/
Phase Amps
BTU Load
Base/Rail
Evap. BTU/°TD
Base/Rail
# of
Pans
F18RR44 (2) 19” 70 9.49 5.12 115/60/1 3.0 547/441 120/5°/19/23° 10
F18RR52 (1) 19” & (1) 27” 70/124 11.81 6.51 115/60/1 3.0 625/529 120/5°/23/23° 12
F18RR60 (2) 27” 124 14.14 7.9 115/60/1 5.0 703/617 120/6°/26/24° 16
F18RR70 (2) 32” 140 17.05 9.64 115/60/1 5.0 800/794 120/7°/32/24° 18
F18RR79 (1) 19” & (2) 27” 70/124 18.68 10.29 115/60/1 5.0 962/882 240/4°/36/25° 18
F18RR87 (3) 27” 124 21.30 11.85 115/60/1 5.0 1032/970 240/4°/39/25° 22
Self-Contained Refrigerated Reduced Height Rail
Model # Of Doors
Shelf Max
Load (lbs)
Base Volume
FT
3
Shelf
Area FT
2
Volts/Hertz/
Phase Amps
BTU Load
Base/Rail
BTU System
Cap. Base/Rail
# of
Pans
R-404A
oz. H.P.
NEMA
Plug
F18RC52 (2) 19” 70 9.49 5.12 115/60/1 10.0 547/529 1903/1061 12 16 1/4 5-15P
F18RC60 (1) 19” & (1) 27” 70/124 11.81 6.51 115/60/1 12.0 625/617 2314/1121 14 24 1/3 5-15P
F18RC68 (2) 27” 124 14.14 7.9 115/60/1 12.0 703/794 2314/1544 16 24 1/3 5-15P
F18RC82 (2) 32” 140 17.05 9.64 115/60/1 14.0 800/882 3097/1648 20 32 1/2 5-20P
F18RC91 (1) 19” & (2) 27” 70/124 18.68 10.29 115/60/1 14.0 962/1058 3807/1839 22 32 1/2 5-20P
F18RC99 (3) 27” 124 21.30 11.85 115/60/1 14.0 1032/1147 3807/1839 24 32 1/2 5-20P
Remote Freezer Base
Model # Of Doors
Shelf Max
Load (lbs)
Base Volume
FT
3
Shelf
Area FT
2
Volts/Hertz/
Phase Amps
BTU Load
Base/Rail Evap. BTU/°TD
F18FR35 (1) 19” 70 5.58 2.56 115/60/1 10.0 943 160/6°
F18FR50 (2) 19” 70 12.21 5.12 115/60/1 10.0 1471 160/9°
F18FR58 (1) 19” & (1) 27” 70/124 15.00 6.51 115/60/1 10.0 1844 160/10°
F18FR66 (2) 27” 124 17.79 7.9 115/60/1 10.0 2020 160/11°
F18FR76 (2) 32” 140 21.28 9.64 115/60/1 10.0 2437 160/13°
Self-Contained Freezer Base
Model # Of Doors
Shelf Max
Load (lbs)
Base Volume
FT
3
Shelf
Area FT
2
Volts/Hertz/
Phase Amps
BTU Load
Base/Rail
BTU System
Cap. Base/Rail H.P.
R-404A
oz.
NEMA
Plug
F18FC43 (1) 19” 70 5.58 2.56 115/60/1 10.0 943 1558 1/3 24 5-15P
F18FC62 (2) 19” 70 12.21 5.12 115/60/1 12.0 1471 1776 1/2 40 5-15P
F18FC70 (1) 19” & (1) 27” 70/124 15.00 6.51 115/60/1 16.0 1647 2713 3/4 56 5-20P
F18FC78 (2) 27” 124 17.79 7.9 115/60/1 16.0 1824 2713 3/4 56 5-20P
F18FC88 (2) 32” 140 21.28 9.64 115/60/1 16.0 2045 2713 3/4 56 5-20P
Self-Contained Dual Rails
Model # Of Doors
Shelf Max
Load (lbs)
Base Volume
FT
3
Shelf
Area FT
2
Volts/Hertz/
Phase Amps
BTU Load
Base/Rail
BTU System
Cap. Base/Rail H.P.
R-404A
oz.
NEMA
Plug
F18PD48 (1) 27” 124
9.38 3.95
115/60/1 10.0 424/1058 2001/1865 1/5, 1/3 40 5-20P
F18PD72 (2) 27” 124
16.64 7.90
115/60/1 12.7 703/1588 2001/3174 1/5. 1/2 48 5-20P
