Delfield CoolScapes GBF2P-S User Manual

28 pages

To Next Page

To Next Page

Page #1 background image

Loading...

Page #1 background image

Series GC, GB & GBS Reach-Ins

CoolScapes™

Original Instructions

Installation, Operation and Maintenance Manual

This manual is updated as new information and models are released. Visit our website for the latest manual.

Part Number: 9294839 03/17

Table of Contents

Questions and Answers:

W
Walter SmithAug 16, 2025
Why is my Delfield CoolScapes GBF2P-S temperature too high?
- K
  Kimberly MendozaAug 16, 2025
  If your Delfield Refrigerator's cabinet temperature is too high, there are several potential causes. Begin by ensuring the thermostat is set to a lower temperature. Check for and correct poor air circulation by rearranging the product inside. Recalibrate the exterior thermometer if it's out of calibration. Allow adequate time for warm products to cool down. Minimize prolonged door openings, ensure the doors are properly closed, and clean the condenser coil. Finally, if the evaporator coil is iced over, turn off the unit to defrost, and verify the thermostat isn't set too cold, also check the door gasket condition.
K
kathryn42Aug 19, 2025
What does E13 mean on a Delfield Refrigerator display?
- T
  Tamara ReyesSep 12, 2025
  If the temperature display on your Delfield Refrigerator reads E13, it indicates a communication error between the controller and the display. First, check for loose plugs on the cable connecting the control to the display. If the plugs are secure, the display or control may need to be replaced.
K
Kristy CunninghamAug 22, 2025
What does E6 error mean on Delfield Refrigerator?
- D
  David FergusonAug 22, 2025
  If the temperature display on your Delfield Refrigerator reads E6, it means the control has a defective potentiometer. Replace the control to resolve this issue.
V
Vincent MartinAug 26, 2025
What does E2 error mean on Delfield CoolScapes GBF2P-S?
- C
  Carrie FisherAug 26, 2025
  If the temperature display on your Delfield Refrigerator reads E2, the coil temperature sensor circuit is either open or shorted. Check the sensor's resistance for an open or short circuit. If either condition is found, replace the sensor. If the sensor is fine, the control may need to be replaced.
B
brianrichardsonAug 28, 2025
What does E1 mean on Delfield CoolScapes GBF2P-S display?
- T
  Todd MorrisAug 28, 2025
  If the temperature display on your Delfield Refrigerator reads E1, it indicates that the box temperature sensor circuit is either open or shorted. To solve this, check the resistance of the sensor for an open or short circuit. If either condition is found, replace the sensor. If the sensor checks out, the control might need replacing.
M
Morgan SpencerAug 31, 2025
Why is my Delfield CoolScapes GBF2P-S Refrigerator running constantly?
- N
  Nicholas JohnsonAug 31, 2025
  If your Delfield Refrigerator's condensing unit runs for extended periods or continuously, it could be due to several reasons. First, check if you've placed an excessive amount of warm product inside; allow sufficient time for cooling. Ensure doors are closed when not in use to prevent prolonged openings. Inspect door gaskets for proper sealing, adjusting the door or replacing the gasket if needed. Clean the condenser coil, and if the evaporator coil is iced over, turn off the unit to defrost it, ensuring the thermostat isn't set too cold and that the gasket is in good condition.
M
Michele WalshSep 3, 2025
How to fix a Delfield CoolScapes GBF2P-S Refrigerator that is not running?
- K
  Kelli SimsSep 3, 2025
  If your Delfield Refrigerator cabinet isn't running, check the following: First, replace the fuse or reset the circuit breaker if it has blown or tripped. Ensure the power cord is plugged in. Adjust the thermostat to a lower temperature if it's set too high. Turn the main power switch on if it's off. If it's a freezer model, wait for the defrost cycle to complete.
N
Natasha AlvaradoSep 6, 2025
What to do if Delfield Refrigerator is freezing food?
- G
  Grant SmithSep 6, 2025
  If your Delfield Refrigerator is freezing product, the thermostat might be set too low; try setting it to a higher temperature. A dirty condenser coil can also cause this issue, so cleaning it may help. Lastly, ensure there's enough cabinet clearance for proper refrigeration system operation; adjust the cabinet's position to improve clearance if needed.
R
Rebecca AndersonSep 9, 2025
Why won't the compressor start on my Delfield Refrigerator?
- A
  ashley88Sep 9, 2025
  If your Delfield Refrigerator's compressor will not start, the issue might be due to low voltage. Check the incoming voltage to the cabinet and correct it as necessary.

Delfield CoolScapes GBF2P-S Specifications

General

Brand	Delfield
Model	CoolScapes GBF2P-S
Category	Refrigerator
Language	English

Summary

Installation

Location and Site Requirements

Criteria for selecting and preparing the installation location, including clearances.

Electrical Service and Power Details

Details on voltage, circuit protection, GFCI, and power cord requirements.

Leveling, Stabilizing, and Leg/Caster Installation

T-1 Tray Slide Installation

T-2 Tray Slide Installation

T-3 Tray Slide Installation

T-4 Rack Slide Installation

Operation

R290 Refrigerator Operation and Defrost

Covers initial start-up, defrost modes, and temperature control for refrigerators.

R290 Freezer Operation and Defrost

Details operation, automatic/manual defrost, and temperature control for freezers.

Temperature Control Display Statuses

Temperature Control Adjustments and Power Switch

How to adjust temperature set-points, use power switch, and energy saver.

Maintenance

General Safety and Cleaning Guidelines

Safety warnings and general guidelines for maintenance and cleaning procedures.

Troubleshooting

Cabinet Running and Temperature Issues

Troubleshooting for common problems like the cabinet not running or temperature being too high.

Noise, Freezing, and Compressor Problems

Solutions for noise, product freezing, compressor start issues, and loose parts.

Sensor Error Codes and Display Issues

Explains sensor error codes (E1, E2, E6) and display communication errors (E13).
