Series GC, GB & GBS Reach-Ins
CoolScapes™
Original Instructions
Installation, Operation and Maintenance Manual
This manual is updated as new information and models are released. Visit our website for the latest manual.
Part Number: 9294839 03/17

Table of Contents

Questions and Answers

  • T
    Tracey BautistaAug 15, 2025
    Why is my Delfield Refrigerator temperature too high?
    • M
      Michelle WoodAug 16, 2025
      If your Delfield Refrigerator's cabinet temperature is too high, there are several potential causes. Begin by ensuring the thermostat is set to a lower temperature. Check for and correct poor air circulation by rearranging the product inside. Recalibrate the exterior thermometer if it's out of calibration. Allow adequate time for warm products to cool down. Minimize prolonged door openings, ensure the doors are properly closed, and clean the condenser coil. Finally, if the evaporator coil is iced over, turn off the unit to defrost, and verify the thermostat isn't set too cold, also check the door gasket condition.
  • K
    Kelly FordAug 18, 2025
    What does E13 mean on a Delfield CoolScapes GBSF2P-S Refrigerator display?
    • J
      Jacob MillerAug 19, 2025
      If the temperature display on your Delfield Refrigerator reads E13, it indicates a communication error between the controller and the display. First, check for loose plugs on the cable connecting the control to the display. If the plugs are secure, the display or control may need to be replaced.
  • J
    james14Aug 21, 2025
    What does E6 error mean on Delfield Refrigerator?
    • A
      athomasAug 22, 2025
      If the temperature display on your Delfield Refrigerator reads E6, it means the control has a defective potentiometer. Replace the control to resolve this issue.
  • J
    James ObrienAug 25, 2025
    What does E2 error mean on Delfield CoolScapes GBSF2P-S Refrigerator?
    • S
      Samuel ChristensenAug 26, 2025
      If the temperature display on your Delfield Refrigerator reads E2, the coil temperature sensor circuit is either open or shorted. Check the sensor's resistance for an open or short circuit. If either condition is found, replace the sensor. If the sensor is fine, the control may need to be replaced.
  • S
    Sandra HaynesAug 28, 2025
    What does E1 mean on Delfield CoolScapes GBSF2P-S display?
    • E
      Emily KingAug 28, 2025
      If the temperature display on your Delfield Refrigerator reads E1, it indicates that the box temperature sensor circuit is either open or shorted. To solve this, check the resistance of the sensor for an open or short circuit. If either condition is found, replace the sensor. If the sensor checks out, the control might need replacing.
  • S
    Sara SimpsonAug 30, 2025
    Why is my Delfield CoolScapes GBSF2P-S Refrigerator running constantly?
    • T
      tammyperezAug 30, 2025
      If your Delfield Refrigerator's condensing unit runs for extended periods or continuously, it could be due to several reasons. First, check if you've placed an excessive amount of warm product inside; allow sufficient time for cooling. Ensure doors are closed when not in use to prevent prolonged openings. Inspect door gaskets for proper sealing, adjusting the door or replacing the gasket if needed. Clean the condenser coil, and if the evaporator coil is iced over, turn off the unit to defrost it, ensuring the thermostat isn't set too cold and that the gasket is in good condition.
  • K
    Kelly TorresSep 3, 2025
    How to fix a Delfield CoolScapes GBSF2P-S that is not running?
    • A
      Allison ThomasSep 3, 2025
      If your Delfield Refrigerator cabinet isn't running, check the following: First, replace the fuse or reset the circuit breaker if it has blown or tripped. Ensure the power cord is plugged in. Adjust the thermostat to a lower temperature if it's set too high. Turn the main power switch on if it's off. If it's a freezer model, wait for the defrost cycle to complete.
  • M
    Michael JohnsonSep 5, 2025
    What to do if Delfield CoolScapes GBSF2P-S Refrigerator is freezing food?
    • J
      jacobfowlerSep 6, 2025
      If your Delfield Refrigerator is freezing product, the thermostat might be set too low; try setting it to a higher temperature. A dirty condenser coil can also cause this issue, so cleaning it may help. Lastly, ensure there's enough cabinet clearance for proper refrigeration system operation; adjust the cabinet's position to improve clearance if needed.
  • M
    Marilyn HerreraSep 9, 2025
    Why won't the compressor start on my Delfield CoolScapes GBSF2P-S Refrigerator?
    • S
      sgarciaSep 9, 2025
      If your Delfield Refrigerator's compressor will not start, the issue might be due to low voltage. Check the incoming voltage to the cabinet and correct it as necessary.
  • S
    Shawn MillerSep 12, 2025
    How to fix a noisy Delfield CoolScapes GBSF2P-S?
    • J
      Justin KellySep 12, 2025
      If your Delfield Refrigerator is making unusual noises, locate and tighten any loose parts.

Summary

Safety Notices

Section 2 Installation

Location Requirements

Electrical Service Requirements

Details on power supply, voltage, and connection requirements.

Leveling and Stability

Leg & Caster Installation

Steps for installing legs or casters on the unit.

Reversible Door Instructions

T-1 Tray Slide Installation

T-2 Tray Slide Installation

T-3 Tray Slide Installation

T-4 Rack Slide Installation

Section 3 Operation

R290 Controls;Programming;Settings

Overview of refrigerator and freezer controls, programming, and defrost modes.

R290 Temperature Control & Display

Details on the temperature control unit and its display functions.

R290 Power Switch

Information on the unit's main power disconnect switch.

R290 Temperature Alarm

R290 Evaporator Fan Operation

How the evaporator fan operates during cooling and defrost cycles.

R290 Celsius Display Change

Section 4 Maintenance

Cleaning and Sanitizing Procedures

General guidelines for cleaning and sanitizing the equipment.

Interior Cleaning

Instructions for cleaning the inside of the unit.

Exterior Cleaning

Instructions for cleaning the exterior surfaces of the unit.

Condenser Coil Cleaning

Section 5 Troubleshooting

Problem-Cause-Correction Chart

A guide to diagnose and resolve common issues.
