Delfield F18 Series User Manual

F18 Series Service and Installation Manual
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com
6
Specifications
Remote Refrigerated Salad Top Tables
Model # Of Doors
Shelf Max
Load (lbs)
Base Volume
FT
3
# of
Pans
Volts/Hertz/
Phase Amps
BTU Load
Base/Rail
Evap. BTU/°TD
Base/Rail
F18SR31A (1) 19” 70 4.14 6 115/60/1 3.0 280/265 120/2°/13/21°
F18SR44A (2) 19” 70 7.15 6 115/60/1 3.0 491/441 120/4°/13/21°
F18SR44B (2) 19” 70 7.15 8 115/60/1 3.0 491/441 120/4°/16/22°
F18SR44C (2) 19” 70 7.15 10 115/60/1 3.0 491/441 120/4°/19/23°
F18SR52A (1) 19” & (1) 27” 70/124 8.97 6 115/60/1 3.0 532/529 120/4°/13/21°
F18SR52B (1) 19” & (1) 27” 70/124 8.97 8 115/60/1 3.0 532/529 120/4°/16/22°
F18SR52C (1) 19” & (1) 27” 70/124 8.97 10 115/60/1 3.0 532/529 120/4°/19/23°
F18SR52D (1) 19” & (1) 27” 70/124 8.97 12 115/60/1 3.0 532/529 120/4°/23/23°
Self-Contained Refrigerated Salad Top Tables
Model # Of Doors
Shelf Max
Load (lbs)
Base Volume
FT
3
# of
Pans
Volts/Hertz/
Phase Amps
BTU Load
Base/Rail
BTU System
Cap. Base/Rail
R-404A
oz. H.P.
NEMA
Plug
F18SC39A (1) 19” 70 4.14 6 115/60/1 10.0 280/265 1903/745 16 1/4 5-15P
F18SC39B (1) 19” 70 4.14 8 115/60/1 10.0 280/353 1903/867 16 1/4 5-15P
F18SC52A (2) 19” 70 7.15 6 115/60/1 10.0 444/265 1903/745 16 1/4 5-15P
F18SC52B (2) 19” 70 7.15 8 115/60/1 10.0 444/353 1903/867 16 1/4 5-15P
F18SC52C (2) 19” 70 7.15 10 115/60/1 10.0 444/441 1903/971 16 1/4 5-15P
F18SC52D (2) 19” 70 7.15 12 115/60/1 10.0 444/529 1903/1061 16 1/4 5-15P
F18SC60A (1) 19” & (1) 27” 70/124 8.97 6 115/60/1 10.0 515/265 2314/667 16 1/4 5-15P
F18SC60B (1) 19” & (1) 27” 70/124 8.97 8 115/60/1 10.0 515/353 2314/798 16 1/4 5-15P
F18SC60C (1) 19” & (1) 27” 70/124 8.97 10 115/60/1 10.0 515/441 2314/916 16 1/4 5-15P
F18SC60D (1) 19” & (1) 27” 70/124 8.97 12 115/60/1 10.0 515/529 2314/1023 16 1/4 5-15P
Remote Refrigerated Reduced Height Rail
Model # Of Doors
Shelf Max
Load (lbs)
Base Volume
FT
3
Shelf
Area FT
2
# of
Pans
Volts/Hertz/
Phase Amps
BTU Load
Base/Rail
Evap. BTU/°TD
Base/Rail
F18DR44 (2) 19” 70 9.54 5.12 10 115/60/1 3.0 547/441 120/5°/19/23°
F18DR52 (1) 19” & (1) 27” 70/124 13.89 6.51 12 115/60/1 3.0 625/529 120/5°/23/23°
F18DR60 (2) 27” 124 16.64 7.9 16 115/60/1 5.0 703/617 120/6°/26/24°
F18DR70 (2) 32” 140 22.96 9.64 18 115/60/1 5.0 800/794 120/7°/32/24°
F18DR79 (1) 19” & (2) 27” 70/124 22.47 10.29 18 115/60/1 5.0 962/882 240/4°/36/25°
F18DR87 (3) 27” 124 25.22 11.85 22 115/60/1 5.0 1032/970 240/4°/39/25°
Self-Contained Refrigerated Reduced Height Rail
Model # Of Doors
Shelf Max
Load (lbs)
Base Volume
FT
3
Shelf
Area FT
2
# of
Pans
Volts/Hertz/
Phase Amps
BTU Load
Base/Rail
BTU System
Cap. Base/Rail
R-404A
oz. H.P.
NEMA
Plug
F18DC52 (2) 19” 70 9.54 5.12 12 115/60/1 10.0 547/529 1903/1061 16 1/4 5-15P
F18DC60 (1) 19” & (1) 27” 70/124 13.89 6.51 14 115/60/1 12.0 625/617 2314/1121 24 1/3 5-15P
F18DC68 (2) 27” 124 16.64 7.9 18 115/60/1 12.0 703/794 2314/1544 24 1/3 5-15P
F18DC82 (2) 32” 140 22.96 9.64 20 115/60/1 14.0 800/882 3097/1648 32 1/2 5-20P
F18DC91 (1) 19” & (2) 27” 70/124 22.47 10.29 22 115/60/1 14.0
962/1058 3807/1839 32 1/2 5-20P
F18DC99 (3) 27” 124 25.22 11.85 24 115/60/1 14.0 1032/1147 3807/1839 32 1/2 5-20P

Delfield F18 Series Specifications

General

Brand	Delfield
Model	F18 Series
Category	Refrigerator
Language	English
