Part Number: 9291457 6/19 13
Section 2 Installation
Drain Connections
Self-contained equipment stands come standard with a
condensate evaporator. If the condensate evaporator fails,
the unit’s drain must have an outlet to an appropriate
drainage area or container.
n
Warning
Moisture collecting from improper drainage can create a
slippery surface on the floor and a hazard to employees.
It is the owner’s responsibility to provide a container or
outlet for drainage.
Leveling
After the cabinet has been placed in the desired location,
cabinets with legs must be leveled. Level units from front to
back and from side to side. Leveling will insure proper door
operation and removal of condensate. Cabinets with casters
must have the caster brake set so the cabinet cannot move.
Stabilizing
It is very important that all legs are properly adjusted to
keep the cabinet level, evenly distribute the weight and to
make sure the unit will not rock, lean or be unstable.
Leg & Caster Installation
DANGER
Legs or casters must be installed and the legs or casters
must be screwed in completely to prevent bending.
When casters are installed the mass of this unit will
allow it to move uncontrolled on an inclined surface.
These units must be tethered/secured to comply with
all applicable codes.
n
Warning
The unit must be installed in a stable condition with
the front wheels locked. Locking the front casters after
installation is the owner’s and operator’s responsibility.
n
Warning
Use a jack to lift the refrigeration unit off the ground
just far enough to remove the leg/caster. Place blocking
underneath the unit. Do not work underneath a raised
unit without proper blocking. Do not lift the unit more
than necessary to remove the leg/caster. Lifting the unit
too far can make the unit unstable.
Refrigeration
Model BTU System
Capacity
Heat of
Rejection
R290
Charge
Refrigerated Base
F17C52P 1600 367 150g
F17C60P 1600 473 150g
F17C62P 1600 488 150g
F17C73P 2074 574 150g
F17C75P 2074 590 150g
F17C78P 2074 613 150g
F17C87P 2508 755 150g
F17C110P 2893 935 150g
Dry Drawer
F17DD Series NA
Freezer Base
F17FC94P 2567 1271 (2) 150g
Open Shelf
F17OS Series NA
Low-Profile Freezer Base
F2660CP,
F2660P
1365 468 (2) 150g
F2694CP,
F2694P
1365 816 (2)150g
Low-Profile Refrigerator Base
F2936CP,
F2936P
1064 224 105g
F2952CP,
F2952P
1600 283 150g
F2956CP,
F2956P
1600 283 150g
F2960CP,
F2960P
1600 365 150g
F2962CP,
F2962P
1600 365 150g
F2973CP,
F2973P
2071 441 150g
F2975CP,
F2975P
2071 441 150g
F2978CP,
F2978P
2071 471 150g
F2980CP,
F2980P
2071 471 150g
F2987CP,
F2987P
2508 588 150g
F2996CP,
F2996P
2508 634 150g
F2999CP,
F2999P
2508 634 150g
F29110CP,
F29110P
2893 723 150g
