Part Number: 9291457 6/19 23
Section 4 Maintenance
Drawer Assembly Cleaning
The drawer assembly is designed to be cleaned easily. Both
drawer and tracks are removable without tools. The drawer
tracks are dishwasher safe or can be cleaned in a sink with
detergents and a soft bristle brush. Drawers and tracks
should be cleaned on a weekly basis.
Remove Drawers
Pull the drawer box out until it stops. Lift up on the drawer
front and pull the drawer box completely out. Using a soft
bristle brush, clean the track on the bottom of the drawer
box. When finished, it should be wiped clean of all food and
debris.
Tracks
The drawer box assembly must be removed. Pull the drawer
tracks out until they hit a stop. Locate blue safety clips
towards the back of each drawer track. Blue safety clips
have a tab on the top. Push the tab back until it clicks. Lift
up and pull the drawer tracks all the way out of the drawer
cage. The drawer tracks
are dishwasher safe
or can be cleaned in a
sink with detergents
and a soft bristle brush.
Drawers and tracks
should be cleaned on
a weekly basis. Using a soft bristle brush, wash the track
making sure each roller is thoroughly cleaned. The drawer
cage should be cleaned with a soft bristle brush, removing
any food and debris gathered on the bottom ledge. Once
it’s cleaned thoroughly with a soft bristle brush, wipe
remaining debris clean with a soft towel.
Reassembly
Push the drawer tracks into the drawer cage. The blue safety
clip must remain pushed towards the back. Lift up and slide
the drawer track all the way into the drawer cage. The blue
safety clip will lock in place automatically. Once all tracks
are replaced, insert the drawer box. Rest the drawer box
bottom track on the front track roller. Then push the drawer
back in place SLOWLY. When the drawer box is about half
way in you will hit a STOP. You must lift the front of the
drawer up approximately ½” (1.3cm) to continue inward.
Clean tracks as often as possible. The cleaner the tracks are
the better they will operate.
Cleaning The Condenser Coil
In order to maintain proper refrigeration performance, the
condenser fins must be cleaned of dust, dirt and grease
regularly. It is recommended that this be done monthly. If
conditions are such that the condenser is totally blocked
in a month, the frequency of cleaning should be increased.
Clean the condenser with a vacuum cleaner or stiff brush. If
extremely dirty, a commercially available condenser cleaner
may be required.
Failure to maintain a clean condenser coil can initially cause
high temperatures and excessive run times. Continuous
operation with a dirty or clogged condenser coil can
result in compressor failure. Neglecting the condenser coil
cleaning procedures will void any warranties associated
with the compressor and cost to replace the compressor.
Cleaning The Condensate Evaporator
(Remote Models Only)
The stainless steel condensate evaporator pan should be
cleaned every six months. Use a vacuum cleaner or damp
cloth to remove dust that may have accumulated. This will
prevent corrosion of the stainless steel.
tab on top of
blue safety clip
