Dell 1707FPc - Rear Cover and Shield Removal

Dell 1707FPc
44
2. Pry the monitor up then find
out the hooks’ position, use the
tool (like the picture or other
card) to insert into the gap of
bezel and rear cover.
3. Take off the bezel
Remove rear cover :
Turn over the monitor as the Fig,
hold the rear cover, and then
slightly remove it.
