Electrical Specifications
Video input signals
Analog RGB, 0.7 Volts +/- 5%, positive polarity at 75 ohm input
impedance
Digital DVI-D TMDS, 600mV for each differential line, positive polarity at
50 ohm input impedance
Synchronization input signals
Separate horizontal and vertical synchronizations, polarity-free TTL level,
SOG (Composite SYNC on green)
AC input voltage/frequency/current 100 to 240 VAC/50 or 60 Hz +
3 Hz/1.5A (Max.)
Inrush current
120 V: 30 A (Max.)
240 V: 60 A (Max.)
