Setting up the monitor
Attaching the stand
NOTE: The stand is not installed at the factory when shipped.
NOTE: The following instructions are applicable only for attaching the stand
that was shipped with your monitor. If you are attaching a stand that you
purchased from any other source, follow the set up instructions that were
included with the stand.
To attach the monitor stand:
1. Follow the instructions on the flaps of carton to remove the stand from the top
cushion that secures it.
2. Remove the stand riser and stand base from the packaging cushion.
3. Insert the stand base blocks fully into the stand slot.
4. Lift the screw handle and turn the screw clockwise.
5. After fully tightening the screw, fold the screw handle flat within the recess.
