44 │ Setting up the monitor
VESA wall mounting (optional)
(Screw dimension: M4 x 10 mm).
Refer to the instructions that come with the VESA-compatible wall mounting kit.
1. Place the monitor panel on a soft cloth or cushion on a stable flat table.
2. Remove the stand. (See Removing the monitor stand)
3. Use a Phillips crosshead screwdriver to remove the four screws securing the
plastic cover.
4. Attach the mounting bracket from the wall mounting kit to the monitor.
5. Mount the monitor on the wall. For more information, see the documentation that
shipped with the wall mounting kit.
NOTE: For use only with UL or CSA or GS-listed wall mount bracket with
minimum weight or load bearing capacity of 20.2 kg (44.53 lb).
