Dell 2209WA - Using the Tilt, Swivel, and Vertical Extension

The Dell Soundbar is a stereo two channel system adaptable to mount on Dell Flat Panel Displays. The Soundbar has a rotary volume and on/off control to
adjust the overall system level, a blue LED for power indication, and two audio headset jacks.

Using the Tilt, Swivel, and Vertical Extension
Tilt,Swivel
With the built-in pedestal, you can tilt the monitor for the most comfortable viewing angle.
1.
Attach mechanism
2.
Headphone jacks
3.
Power indicator
4.
Power/Volume control
NOTE: The stand is detached and extended when the monitor is shipped from the factory.
