Dell 2209WA - Monitor Specifications; Flat Panel Specifications

Monitor Specifications
Flat Panel Specifications
*[2209WA] color gamut (typical) is based on CIE1976 (83%) and CIE1931 (72%) test standards.
Screen type
Active matrix - TFT LCD
Panel type
e-IPS
Screen dimensions
22 inches (22-inch viewable
image size)
Preset display area:
473.76(H)X296.1(V)
Horizontal
473.76 mm (18.7 inches)
Vertical
296.1 mm (11.7 inches)
Pixel pitch
0.282 mm
Viewing angle
178°(vertical)typical
178°(horizontal)typical
Luminance output
300 CD/m²(typical)
Contrast ratio
1000 to 1 (typical), 3000 to 1
(typical Dynamic Contrast On)
Faceplate coating
Antiglare with hard-coating 3H
Backlight
CCFL (6 U-lamp) direct
backlight system
Response Time
6ms panel typical (Grey to
Grey)
Color depth
16.7 million colors
Color Gamut
83%*
