Dell 2408WFP - Card Reader Specifications

USB Ports
l 1 upstream - rear
l 4 downstream - 2 on rear; 2 on left side
Card Reader Specifications
Overview
l The Flash Memory Card Reader is a USB storage device that allows users to read and write information from and into the memory card.

l The Flash Memory Card Reader is automatically recognized by Windows®2000, XP and Vista.

l Once installed and recognized, each separate memory card (slot) appears as a separate drive/drive letter.

l All standard file operations (copy, delete, drag-and-drop, etc.) can be performed with this drive.
Features
The Flash Memory Card Reader has the following features:
l Supports Windows 2000, XP and Vista operating systems

l No Windows 9X support from Dell

l Mass Storage Class device (No drivers are required under Windows 2000, XP and Vista)

l USB-IF certification

l Supports various memory card media

The following table lists the slot to support what kind of memory card:
Maximum Card Capacity Supported by the 2408WFP card reader
4
GND
NOTE:USB2.0capabilityrequires2.0capablecomputer
NOTE: The monitor's USB interface works only when the monitor is on or in power save mode. If you switch
the monitor off and then on, the attached peripherals may take a few seconds to resume normal functionality.
Slot Number
Flash memory cards type
1
Compact Flash type I/II Card (CF I/II)/CF form factor ATA hard drives to USB 2.0 bus
2
xD-Picture Card
Memory Stick Card (MS)/High Speed Memory Stick (HSMS)/Memory Stick Pro Card (MS
PRO)/Memory Stick Duo (with Adapter)
Secure Digital Card (SD)/Mini Secure Digital (with Adapter)/TransFlash Card (with
Adapter)
MultiMedia Card (MMC)/Reduced Size MultiMedia Card (with Adapter)
Card type
Support Specification
Memory Card
Spec Version
Max. capacity
CF
Compact Flash Specification
2.0
128GB
MS
Memory Stick Standard Format Specification
1.40-00
128MB
MSPRO
Memory Stick Pro Standard Format Specifications
1.01-01
32GB
