Dell 2408WFP - Soundbar Attachment and Stand Removal

Attaching the soundbar
Removing the Stand
Complete the following steps to remove the stand:
1. Rotate the stand to allow access to the stand release button.
2. Press and hold the stand release button.
3. Lift the stand up and away from the monitor.
Back to Contents Page

1.
Working from the rear of the monitor, attach Soundbar by aligning the two slots with the two tabs along the bottom rear of the monitor.
2.
Slide the Soundbar to the left until it snaps into place.
3.
Connect the Soundbar with the DC power connector.
4.
Insert the mini stereo plug from the rear of the Soundbar into the computer's audio output jack.
NOTICE: Do not use with any device other than Dell Soundbar
NOTE: Soundbar Power Connector +12V DC output is for optional Soundbar only.
NOTE: TopreventscratchesontheLCDscreenwhileremovingthestand,ensurethatthemonitorisplacedonacleansurface.
