Dell 2408WFP - Back View; Side View

Back View

BackviewBackViewwithmonitorstand

Side View
5
Auto-adjust/Up (+)
6
Power button (with power light indicator)
Label
Description/Use
1
VESA mounting holes (100mm)
(Behind attached base plate)
To mount the monitor.
2
Connectors label
To indicate the positions and types of connectors.
3
Barcode serial number label
To contact Dell for technical support.
4
Security lock slot
To help secure your monitor.
5
Stand release button
To release the stand from the monitor.
6
Regulatory rating label
Lists the regulatory approvals.
7
Dell Soundbar mounting brackets
To attach the optional Dell Soundbar.
8
Lock down/release button
Push the monitor down, press the button to unlock the
monitor, and then lift the monitor to the desired height.
9
Cable management slot
To organize cables by placing them through the slot.
