Dell 2408WFP - On-Screen Display (OSD) Menu


Using the OSD Menu
1. Push the MENU button to launch the OSD menu and display the main menu.
Main Menu for Analog (VGA) Input

B
PIP/PBP Select
Use this button to activate PIP (Picture-in-Picture)/PBP (Picture-by-Picture)modesadjustment.
Pressing this button continually cycles the monitor through the following modes : OFF-->PIP--
>PBP. You will see the following messages
corresponding to the mode selected.

→




→

C
OSD Menu/Select
The Menu button is used to open and exit the on-screen display (OSD), and exit from menus and sub-menus. See
Using the OSD Menu
D
Brightness /Contrast
Hot Key
Use this button for direct access to the "Brightness" and "Contrast" control menu.
D
and
E
Down (-) and Up (+)
Use these buttons to adjust (decrease/increase ranges) items in the OSD menu.
E
Auto Adjust
Use this button to activate automatic setup and adjustment. The following dialog appears on a black screen as the monitor self
the current input:
Auto Adjustment button allows the monitor to self-
adjust to the incoming video signal. After using Auto Adjustment, you can further
tune your monitor by using the Pixel Clock (Coarse), Phase (Fine) controls in the OSD.

NOTE: Auto Adjust does not occur if you press the button while there are no active video input signals or attached cables.
F
Power button
(withpowerlight
indicator)
Usethepowerbuttontoturnthemonitoronandoff.
Thegreenlightindicatesthemonitorisonandfullyfunctional.Anamberlightindicatespowersavemode.
NOTE: Ifyouchangethesettingsandtheneitherproceedtoanothermenu,orexittheOSDmenu,themonitor
automaticallysavesthosechanges.Thechangesarealsosavedifyouchangethesettingsandthenwaitforthe
OSD menu to disappear.
