58 Maintenance
www.dell.com/supplies | support.dell.com
6. Align the arrow marks on the transfer roller to the marks on the printer, and gently push the
roller into the printer.
7. To lock the transfer roller into the printer, push down the tabs until you hear a click.
8. Close the front cover.
