Dell 5330dn - Page 46

To Next Page

To Previous Page

4. Pull the rear door out of the printer.

5. Pull the duplex unit out of the printer.

6. Push both the levers of the fuser and downward both levers of the fuser.

7. Pull the Fuser unit straight out.

Downloaded from ManualsPrinter.com Manuals
