The audio line-out connector is on the side of the APR (see Figure 1-2).
Figure 1-2. Audio Line-Out Connector
APR Controls and Indicators
The controls and indicators on the APR are shown in Figure 1-3.
Figure 1-3. Controls and Indicators
audio line-out connector
docking
indicator
undock request button
power button
power
indicator
drive
access
indicator
eject
position
unlocked
position
locked
position
eject/locking
lever
padlock
slot
security
lock slot
