Replacing the logo board
NOTE: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your computer. After working inside your computer, follow the instructions in After working
inside your computer. For more safety best practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1. Align the screw holes on the logo board to the screw holes on the bracket and slide the logo board in place.
2. Replace the six screws (#6-32x6) that secure the logo board to the bracket.
3. Slide the logo board inside the chassis.
4. Replace the screw (#6-32x6) that secures the logo board to the bracket.
5. Route and connect the respective cables to the logo board.
Post-requisites
1. Replace the left and right side-panels. See “
Replacing the side panels”.
2. Replace the
stability foot.
