Replacing the top-cover
assembly
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in
Before working inside your computer. After working inside your
computer, follow the instructions in After working inside your
computer. For more safety best practices, see the Regulatory
Compliance home page at www.dell.com/regulatory_compliance.
Procedure
1 Align the tabs on the top cover with the slots on the top bezel and snap the
top cover into place.
2 Slide the lighting cable through the slot on the chassis.
3 Align the tabs on the top cover with the slots on the chassis and snap the
top cover into place.
4 Connect the lighting cable to the top cover.
5 Replace the screws that secure the top cover to the chassis.
Post-requisites
1 Replace the right-side cover.
2 Replace the left-side cover.
