About Your Display | 11
Side View
Label Description Use
1a HDMI 1 connector
Connect your computer with HDMI cable.
1b HDMI 2 connector
1c HDMI 3 connector
1d HDMI 4 connector
2 DP connector Connect your computer with DP cable.
3 VGA connector Connect your computer with VGA cable.
4 Audio line-in port Analog audio (two channel) input.
5 Audio line-out port Connect to external audio peripherals.
Only supports 2-channel audio.
NOTE: The audio line-out port does not support
headphones.
6 USB 3.0 upstream ports
(3)
Connect the USB cable that comes with your display to the
computer. Once this cable is connected, you can use the
USB downstream connectors on the display and the touch
screen function on the display.
