About Your Display | 13
Display Specifications
Screen type Active matrix - TFT LCD
Panel Type In-plane switching Technology
Aspect ratio 16:9
Viewable image dimensions
Diagonal 217.427 cm (85.60 inches)
Active Area
Horizontal 1895.04 mm (75.68 inches)
Vertical 1065.96 mm (41.97 inches)
Area
2020039.84 mm
2
(3131.06 inches
2
)
Pixel pitch 0.4935 mm x 0.4935 mm
Pixel per inch (PPI) 51
Viewing angle
Horizontal 178° (typical)
Vertical 178° (typical)
Panel brightness 360 cd/m² (typical)
Contrast ratio 1200 to 1 (typical)
Display screen coating 7H, Anti-Smudge, Anti-Glare
Response Time 8 ms typical (G to G), 12 ms max (G to G )
Color depth 1.07 Billon colors
Color gamut NTSC ( 72%)
Connectivity •1 x DP 1.2
•1 x VGA
•4 x HDMI 2.0
•3 x USB 3.0 downstream port
•1 x USB Dedicated charging port
USB 3.0 with 12.5W (For WR517 Wireless
receiver(Optional) Power supply (5V/2.5A))
•3 x USB 3.0 upstream port
•1 x Analog 2.0 audio line out (3.5 mm jack)
•1 x Analog 2.0 audio line in (3.5 mm jack)
•1 x RJ-45
•1 x RS232
Border width (edge of display to
active area)
31.9 mm (Top)
31.9 mm (Left/Right)
31.9 mm (Bottom)
To Next Page
