Dell D5000 User Manual

4
Environmental
Characteristics
Temperature
Operating: 0 °C to 40 °C
Non-operating:
 Storage: -20 °C to 60 °C
(-4 °F to 140 °F)
 Shipping: -20 °C to 60 °C
(-4 °F to 140 °F)
Humidity
Operating: 10% to 80%
(non-condensing)
Non-operating:
 Storage: 5% to 90%
(non-condensing)
 Shipping: 5% to 90%
(non-condensing)
Power Supply
19.5 V / 3.34 A (65 W)
Dimension
190 mm x 86 mm x 30.7 mm
DP-VGA Dongle Specifications
High Video Resolution
1920 x 1200 @ 60Hz, 1920 x 1080p @ 60Hz
1600 x 1200 @ 60Hz
Input Voltage
3.3V± 10%
Output Voltage
5V ± 10% (Max 90 mA)
Rated Current
175 mA
Power consumption
575 mW
Standby current
50 mA
Hardware Requirements
Before using the docking station, ensure that your notebook or PC has a WiGig
module and antenna to enable one-to-one wireless connection.

Dell D5000 Specifications

General

Brand	Dell
Model	D5000
Category	Docking Station
Language	English
