Dell DD6800 - Page 53

String
(Loop)
I/O - Port Shelf Port Length
a
1 I/O 7 - Port 0
B controller HOST port of shelf V1.1
2M
1 I/O 2 - Port 0
A controller HOST port of the highest number
shelf in V1
2M
2 I/O 7 - Port 2
B controller HOST port of shelf V2.1
2M
2 I/O 2 - Port 2
A controller HOST port of the highest number
shelf in V2
2M
3 I/O 7 - Port 1
B controller HOST port of shelf V3.1
2M
3 I/O 2 - Port 1
A controller HOST port of the highest number
shelf in V3
2M
4 I/O 7 - Port 3
B controller HOST port of shelf V4.1
3M
4 I/O 2 - Port 3
A controller HOST port of the highest number
shelf in V4
3M
a.
Cable lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be
used.
Connect Cables and Power on
DD6800 and DD9300 (single node, DD Cloud Tier, or ERSO) 53
