String
(Loop)
I/O - Port Shelf Port Length
a
2 I/O 7 - Port 1
A controller HOST port of the second metadata
shelf
2M
2 I/O 2 - Port 1
B controller HOST port of the first metadata shelf
2M
a.
Cable lengths shown are designed for Data Domain racks. Longer cables (up to 5M) can be
used.
Connect Cables and Power on
DD6800 with DD Cloud Tier 63
