Dell DHJC8 - Heat Sink; Removing Heat Sink

2 Install the:
a Heat sink blower
b Side cover
3 Follow the procedure in After working inside your computer.
Heat sink
Removing heat sink
1 Follow the procedure in Before working inside your computer.
2 Remove the:
a Side cover
b 2.5 inch hard drive assembly
c Heat sink blower
3 To remove the heat sink:
a Loosen the four (M3) captive screws that secure the heat sink to the system [1].
NOTE
: The 35 W CPU has four screws and the 65 W CPU has three screws.
b Lift the heat sink away from the system [2].
