94 Appendix
www.dell.com | support.dell.com
Keyboard 6-pin mini-DIN connector or USB
connector
Mouse 6-pin mini-DIN connector or USB
connector
USB two front-panel and two back-panel
USB–compliant connectors
Headphone front-panel miniature connector
Audio
1
three miniature connectors for line-in,
line-out, and microphone
Internally accessible:
Primary IDE channel 40-pin connector on PCI local bus
Secondary IDE channel 40-pin connector on PCI local bus
Floppy drive 34-pin connector
Audio
2
Audio controller Analog Devices AD1885 AC97 Codec
Video
Video controller AGP 4X
Controls and Lights
Power control push button
Power light green
Hard-drive access light green
Diagnostic code lights four bicolor (amber and green) located
on back panel
1
Present only on computers with integrated audio capabilities.
2
Present only on computers with integrated audio capabilities.
Ports and Connectors
(continued)
9p915bk0.book Page 94 Thursday, April 4, 2002 9:26 AM
