Appendix 95
Power
DC power supply:
Wattage 250 W
Heat dissipation 534 BTU (fully-loaded computer
without monitor)
Voltage (switch-selectable
on back panel)
90 to 135 V at 60 Hz;180 to 265 V at 50
Hz;
100 V at 50 to 60 Hz for Japanese
computers
Backup battery 3-V CR2032 coin cell
Physical
Height x Width x Depth 42.5 x 18.1 x 44.7 cm
(16.7 x 7.13 x 17.6 inches)
Weight 12.7 kg (28 lb)
Environmental
Temperature:
Operating 10°
to 35°C (50° to 95°F)
3
Storage –40°
to 65°C (–40° to 149°F)
Relative humidity 20% to 80% (noncondensing)
Maximum vibration:
Operating 0.25 G at 3 to 200 Hz at 1/2 octave/min
Storage 0.5 G at 3 to 200 Hz at 1/2 octave/min
Maximum shock:
Operating bottom half-sine pulse with a change in
velocity of 50.8 cm/sec (20 inches/sec)
Storage 23-G faired-square wave with a velocity
change of 508 cm/sec (200 inches/sec)
9p915bk0.book Page 95 Thursday, April 4, 2002 9:26 AM
