Dell E-Port - Specifications; Physical and Connector Specifications; AC Adapter Power Specifications

Specifications 17
Specifications
Physical
Height
70 mm (2.76 inches)
Depth 180 mm (7.09 inches)
Width 210 mm (8.27 inches)
I/O Connectors
USB six USB connectors: five 4-pin, USB
2.0-compliant connectors; one USB or
eSATA connector
Audio headphones/speakers and microphone
Network one RJ-45 port; 10/100/1000 GB
Ethernet
Dell™ E-Family docking connector one custom connector (Dell E-Family
only)
Video VGA, DVI, DisplayPort (HDMI via
dongle)
USB or eSATA connector one connector supporting USB or
Dell-powered E-Family or standard
self-powered eSATA devices
E-Monitor stand connector one custom connector (Dell E-Family
only)
AC Adapter Power
Input Voltage Wattage Amperage
100–240 VAC, 50–60 Hz 130 W* 1.8 A
100–240 VAC, 50–60 Hz 210 W* 3.2 A
*A laptop with a screen greater than 15.4-inches requires using the 210-W AC adapter.
