Dell E153FPc
38
U102-date Output
NG
Measured DCLK (pin 57 from U102)
DVS, DHS (pin 54,55 from U102)
Is the waveform ok?
DCLK around 48 MHZ, DVS=60.09Hz, DHS around 80
KHz? (Refer to input signal=640x480@60 Hz, and LED is
Green)
OK
Replace ZAN3XL (U102) or
replace Main board.
Check ZAN3/XL (U102)
Signal output (PIN5-14, 106-113,17-26)
Is the waveform ok?
OK
If Main Board being replaced, please
do the DDC – content reprogrammed
OK
NG
To Next Page
