DELL E173FP Service Manual
4
1. MONITOR SPECIFICATIONS
Driving system TFT Color LCD
LCD Panel Size 43cm(17.0")
Pixel pitch 0.264mm(H) x 0.264mm(V)
Viewable angle 140˚ (H) 120˚ (V)
Response time (typ.) 16 ms
Video Analog Only
Input Sync. Type H/V TTL Separate and Composite Sync.
H-Frequency 30kHz – 80kHz
V-Frequency 56-75Hz
Display Colors Over 16.2 million Colors
Dot Clock 135MHz
Max. Resolution 1280 x 1024
Plug & Play VESA DDC2B
TM
Power Consumption ON Mode <35W
Power Saving <2W
Maximum Screen Size
Horizontal : 337.92mm
Vertical: 270.336mm
Power Source
90~264VAC,47~63Hz
Environmental
Considerations
Operating Temp: 0°C to 50°C
Storage Temp.: -20°C to 60°C
Operating Humidity: 10% to 90%
Weight (N. W.) Packaged 5.8Kgs Unit
Unpackaged 4.6Kgs Unit
