9
DDC +5 V
10
GND-sync
11
GND
12
DDC data
13
H-sync
14
V-sync
15
DDC clock
Flat Panel Specifications
* [E1912H] color gamut (typical) is based on CIE1976 (82 %) and CIE1931 (72 %) test standards.
Resolution Specifications
Electrical Specifications
Model number
Dell E1912H monitor
Screen type
Active matrix - TFT LCD
Panel Type
TN
Screen dimensions
47.0 cm (18.5 inches) (18.5-inch wide
viewable image size)
Preset display area:
l Horizontal
l Vertical

409.8 mm (16.14 inches)
230.4 mm (9.07 inches)
Pixel pitch
0.300 mm
Viewing angle:
l Horizontal
l Vertical

170°typical
160°typical
Luminance output
250 cd/m ² (typical)
Contrast ratio
1000 to 1 (typical)
Faceplate coating
Antiglare with hard-coating 3H
Backlight
LED light bar system
Response Time
5 ms typical (black to white)
Color Depth
16.7 mil colors
Color Gamut
82 % (typical) *
Model number
Dell E1912H
Scan range
l Horizontal
l Vertical

30 kHz to 83 kHz (automatic)
56 Hz to 75 Hz (automatic)
Maximum preset resolution
1366 x 768 at 60 Hz
Model number
Dell E1912H monitor
Video input signals
Analog RGB: 0.7 Volts +/- 5 %, 75 ohm input
impedance
Synchronization input signals
Separate horizontal and vertical
synchronizations, polarity-free TTL level, SOG
(Composite SYNC on green)
AC input voltage / frequency / current
100 VAC to 240 VAC/50 Hz or 60 Hz + 3 Hz/1.5 A
(Max.)
Inrush current
120 V: 30 A (Max.)
240 V: 60 A (Max.)
