Dell E193FPc - Power Supply Requirements; Panel Specification

Dell E193FPc
11
4.3 Power Supply Requirements
4.4 Panel Specification
4.4.1 Display Characteristics
For LM190E03-B4 model
For LTM190EX-L01 model
A/C Line voltage range 100 V ~ 240 V± 10 %
A/C Line frequency range 50 ± 3Hz, 60 ± 3Hz
Input Voltage transients 280 volts AC for 10 sec @40℃
Current 0.6A max. at 100V, 0.35A max. at 240 V
Peak surge current
< 60A peak at 240 VAC and cold starting
< 30A peak at 120VAC and cold starting
Leakage current < 3.5mA
Power line surge
No advance effects (no loss of information or defect)
with a maximum of 1 half-wave missing per second
