Dell E193FPc User Manual

Dell E193FPc
5
1. Monitor Specifications
48 cm (19”) a-si TFT Active matrix LCD panel, 0.294mm dot pitch.
16 factory presets, 20 new modes
Vertical refresh rate 55Hz to 75 Hz
Horizontal frequency 30kHz to 80kHz
Resolutions: 640 x 480 up to 1280 x 1024
Universal power supply designed for worldwide application
CE mark
TCO-99
VESA DPMS compliant
VESA DDC compliant
2. LCD Monitor Description
The LCD MONITOR will contain a main board, PWPC board, keypad board, which house the flat panel control
logic, brightness control logic and DDC.
The power board will provide AC to DC Inverter voltage to drive the backlight of panel and the main board chips
each voltage.
Monitor Block Diagram
Video signal, DDC
PWPC board
(Include adapter and Inverter
board)
Flat Panel and
CCFL backlight
Main Board
Keyboard
RS232 Connector
For white balance
adjustment in factory
mode
CCFL Drive.
AC-IN
100-240V
Host Computer
