Dell E193FPc
41
No Backlight
Check C201 (+) =12V
NG
OK
Change F902
Check D201/Q209/Q210/D202/Q211/Q212
Check ON/OFF signal
Check Interface board
NG
OK
Check U201 pin9=12V voltage of C905(+)
NG
OK
Change Q201 or Q202
Check the pin1 of U201 have saw tooth wave
NG
OK
Change U201
Check D201(-), D202(-) have the output of square wave at short time.
NG
OK
CheckQ205/Q207/Q203/Q201 or
/Q206/Q208/Q204/D202
Check the resonant wave of pin2 & pin5 for PT201/ PT202
NG
Check the output of PT201/PT202
Check Q209/Q210/C213 or Q211/C212/C214
Check connecter & lamp
OK
NG
Change PT201/PT202
OK
To Next Page
